100L Vacuum Homogenizing Emulsifier Unit

The 100L Emulsifying Unit is a industrial-grade equipment designed for medium-scale emulsification, homogenization, and mixing. Equipped with a high-power rotor-stator system, it delivers strong shear force for uniform, stable emulsions. Made of 316L stainless steel, it meets FDA, GMP, and CE standards. Featuring digital control, temperature regulation, and safety safeguards, it’s ideal for batch production in cosmetics, pharmaceuticals, food, and fine chemical industries.

Always on time
Acceptable price
Excellent quality

Follow Us:

Contact Us Inquiry Now

Description
Feature&Application
Factory Strength

The 100L Emulsifying Unit is a robust, high-capacity solution tailored for medium-scale industrial production, bridging the gap between pilot trials and large-scale manufacturing. Engineered to deliver consistent emulsification performance, it is a cornerstone for businesses needing reliable, efficient production of emulsified products across diverse sectors.
At its core, the unit boasts a high-torque rotor-stator emulsifying head, driven by a powerful motor, which generates intense mechanical shear and turbulent mixing. This design efficiently breaks down droplets, disperses solids, and eliminates phase separation, ensuring uniform particle size and long-term emulsion stability—critical for products like body lotions, medicinal creams, salad dressings, and industrial coatings.

Constructed with food-grade 316L stainless steel, the 100L tank and contact parts offer exceptional corrosion resistance and easy cleaning, complying with global hygiene standards (FDA, GMP) and reducing cross-contamination risks. The intuitive digital control panel enables precise adjustment of speed (0-2860 RPM) and real-time monitoring of temperature, ensuring repeatable process parameters and consistent product quality. Safety is enhanced by emergency stop buttons and interlock systems that halt operation if the tank cover is opened.
With a space-efficient design suitable for production facilities, the unit features a sturdy frame and optional mobility casters for flexibility. Its modular structure simplifies maintenance and allows integration with auxiliary equipment like vacuum systems or heating/cooling jackets. Widely adopted in cosmetics for bulk skincare production, pharmaceuticals for emulsified drug manufacturing, and food processing for large-batch sauces, the 100L Emulsifying Unit combines reliability, efficiency, and compliance to support scalable industrial operations.
Gangben Mixer Factory produces a variety of vacuum homogenizing emulsifiers. Its homogenizing system is divided into upper homogenization, lower homogenization, and internal-external circulation homogenization; the mixing system adopts positive and negative bidirectional wall-mounted mixing paddles; the lifting system is divided into electric lifting and hydraulic lifting. The factory can customize high-quality emulsifying machine products of various specifications according to customer requirements. The triple mixing adopts imported inverter for speed regulation, which can meet the production needs of different processes.
It adopts imported mechanical seals with excellent performance and German homogenizing structure technology, with the maximum emulsification speed reaching 3400 RPM and the minimum shear fineness reaching 0.2~5μm.
Vacuum defoaming enables materials to meet aseptic requirements, and vacuum suction is adopted—especially for powder materials, as vacuum inhalation can avoid dust flying.
The main pot cover can be equipped with an optional lifting device, which enhances the cleaning effect, and the pot body can be tilted for discharging.
The pot body is welded with three layers of imported stainless steel plates, and the tank body and pipelines are polished or matte-finished, fully complying with GMP requirements.
The tank can heat and cool materials, with the main heating methods being steam heating and electric heating.
To ensure more stable control of the entire machine, the electrical components are imported and fully meet international technical standards.

Application Area

Vacuum emulsifying mixers are used in many application areas, as follows:
Daily chemical products: Used in the production of emulsions, creams, shampoos, shower gels, etc.
Biomedicine: Used in the production of medical emulsions, ointments, oral liquids, etc.
Food industry: Used in the production of emulsified foods, such as yogurt, ice cream, cheese, etc.
Paint and ink: Used in the production of emulsified paints and inks.
Nanomaterials: Used in the preparation of nanomaterials.
Petrochemical industry: Used in the production of emulsified petroleum products.
Printing and dyeing auxiliaries: Used in the production of emulsified paper treatment agents.
Pesticides and fertilizers: Used in the production of emulsified pesticides and fertilizers.
Plastic and rubber: Used in the production of emulsified plastic and rubber materials.
Electric power and electronics industry: Used in the production of emulsified insulation materials and electronic components.
Other fine chemical engineering fields: Such as ceramics, glass, metal processing, etc.

In short, vacuum emulsifying machines have a wide range of applications and are mainly used to produce emulsified products, helping to improve product stability and performance in various industries.
Gangben Mixer Manufacturer specializes in the research, development, production, and sales of mixing machines and filling machines. Its main products include vacuum emulsifying mixers, high-shear emulsifying mixers, vacuum homogenizing emulsifiers, filling and sealing machines, and liquid filling production lines. Equipped with modern production workshops and environments, we adopt advanced equipment manufacturing technologies and strict process quality management and control measures to ensure that all products are free from defects before leaving the factory.

Gangben Mixer Factory has obtained multiple patents for the research and development of emulsifying machines and planetary mixers, as well as ISO quality management system certification and international CE certification. Our products meet quality standards with a reliable quality guarantee. We are committed to manufacturing high-quality mixing machinery to enhance your production efficiency and reduce costs for your company.
